Trimec ES9000 Pre-Load Strike

The Trime ES9000 Pre-Load Strike Brings the latest in technology to the market, the ES9000 represents the next generation in electric strikes.

It offers new features, such as the ability to open with up to 25kg of “pre-load” pressure on the keeper.

It is also extremely flexible offering field selectable fail safe/fail secure and multi-voltage 12-24 volt as standard features.



Features

• Operates under Pre load up to 25kg
• Easy field selectable fail safe/fail secure
• Multi voltage 12v-24v
• Full monitoring
• Continuously Rated Solenoid
• Latch keeper is significantly quieter in operation
• Mounting tabs as standard
• Non handed – field changeable to required configuration
• Australian designed and made



Electrical

• 10 – 30Vdc
• 250mA @12Vdc – 130mA @24Vdc
• Solenoid rated for continuous use
• Polarity and back EMF protected



Performance

• 680kg (1,500lbs) Static strength rating (UL 1034).
• 200,000cycles endurance rating @ 25kg pre-load (based on EN12209, Grade Y)
• Suitable for 15mm latch with 3mm door gap



Monitoring

• Solenoid Monitor – 1 amp NO/NC microswitch
• Door/Latch Monitor – 1 amp NO/NC microswitch



Certification

• AS4145 2008. Compliant to the highest levels of strength and durability when used with an approved lockset.
• C-tick & CE compliant
• 4 hour fire rating, when used with approved door (in accordance with AS1905.1-1997, Part 1: Fire resistant Door sets)
