Description

TVT Intercom Indoor Touchscreen

7 inch IPS touch screen
A maximum of 6 indoor stations can be installed in the same room
Support live preview of the linked camera
Support snapshot when calling via door station (micro SD card required)
Support mute notification function
Use the advanced noise suppression and echo cancellation technology to ensure high sound quality
8CH zone alarm access function
Self-define door opening password
Support 2.4G WIFI
Support 1CH 12V200mA power output for powering up a sensor

System	Operating System
Display	Display Screen
Display Resolution	1024 × 600 , brightness:300 cd/m2
Operation Method	Capacitive touch screen
Video	Video Input
Network Input Resolution	6MP/5MP/4MP/3MP/1080P/1280×1024/960P/720P/960H/D1/CIF
Audio	Local Input
Local Output	Built-in speaker
Compression	G.711(U/A)
Record	Resolution
Frame Rate	NTSC: 30fps; PAL:25fps
Playback	Simultaneous Playback
Performance	Linked IPC
Linked Indoor Extensions	Max. 5
Network	Interface
Wireless Network	WiFi 802.11b/g/n
Protocol	TCP / IP, DHCP, DNS, NTP, etc.
Incoming/Outgoing Bandwidth	40/40Mbps
Interface	Audio
Storage	Built-in micro SD card slot, up to 256GB
Reset	Yes
Alarm Input	8CH
Wi-Fi	Yes,2.4G Wi-Fi
Unlocking Button	Yes
RS 485	Reserved
Power Output	DC12V 200mA (only available when DC12V power supply is used)
Others	Power
Power Consumption	< 6W
Dimensions(mm)	180.6 135.6 26.8
Weight (net)	Approx.0.36kg
Installation	Wall mounting
Working Environment	-20℃ ~50℃, Humidity: less than 95% (non-condensing)
Certificate	CE, FCC
Environmental Protection	Complies with Directive EU RoHS, REACH and WEEE
