AJAX MultiTransmitter Wireless Wired-to-Wireless Integration Module | Supply & Certified Installation Wellington

Description

Strict Professional Installation Policy: To ensure your wireless network operates securely on local AU/NZ frequencies and to safeguard your manufacturer warranty, Beveridge Security only provides professional setup and physical installation services for AJAX hardware purchased directly from our store. We strictly do not provide programming, app integration, or layout configuration for customer-supplied items or products purchased from unauthorized online retailers.

Upgrade Legacy Wired Alarms Into A Smart Wireless Ecosystem

The AJAX MultiTransmitter is the ultimate retrofitting integration module designed to breathe smart, modern life into old, traditional hardwired security setups. Operating on localized **AU/NZ Jeweller radio frequencies**, this powerful unit connects your existing physical window contacts, motion beams, and panic buttons directly to your smart system. Instead of spending thousands tearing down solid walls to run new cables, the MultiTransmitter acts as a bridge. It converts standard electrical signals from your old hardware into instant, encrypted wireless notifications, upgrading your home or office infrastructure in a single afternoon.

Full Technical Specifications & System Capacity

As Wellington’s authorized security experts, we have compiled the complete technical capabilities of the MultiTransmitter integration module below. This system allows us to reuse your existing infrastructure investments while maximizing security capability:

• Premium Aesthetic Profile & Color Options: Available in both high-gloss Black or clean matte White housing enclosures, perfectly packing away all your wiring blocks and circuitry out of sight inside closets or utility hubs.
• 18 Hardwired Zone Terminal Inputs: Features 18 independent wire terminals that fully support NO, NC, EOL, 2EOL, and 3EOL electrical line configurations, allowing for precise zone parsing.
• Flexible Multi-Device Event Typing: Each connected line can be programmed by our technicians into specific alert groups, including burglary, fire alarm, medical panic, gas alert, or smart tamper warnings.
• Long-Range Secure Jeweller Link: Utilizes the encrypted Jeweller radio protocol to transmit all hardwired sensor events back to the main control panel at ranges up to 2,000 meters in open space.
• Dedicated Power Output Lines: Equipped with dual internal 12V DC power lines capable of delivering up to 1 Amp of total continuous current to power older motion trackers or barrier beams.
• Double-Layer Anti-Tamper Enclosure: The protective casing features dual active tamper triggers that register instant alerts if the front plate is removed or if the box is pulled away from the wall structure.
• Main Grid Backup Battery Housing: Designed with a dedicated internal slot to cleanly mount a backup 12V lead-acid battery (up to 7 Ah capacity), keeping all 18 wired zones running for days if local mains power drops out.
• Instantaneous Transmission Processing: Employs lightning-fast signal translation algorithms to process any hardware wire break and push an alert to your smartphone screen in just 0.15 seconds.

Why Choose Beveridge Security for Your AJAX Wireless Security?

• Certified AJAX Security Installers in Wellington: Configuring Jeweller wireless technology and configuring multi-path communication requires factory-trained expertise. Our mobile security technicians professionally map your signal strengths, eliminate wireless blind spots, and pair your hubs seamlessly to prevent false alarms.
• Complete System Integration & Testing: We handle the entire technical setup from scratch. Our mobile field security technicians and tech experts securely mount your devices, program smart automation scenarios, calibrate pet-immune motion sensors, and link the system directly to your smartphone app.
• Local Warranty & Ongoing Support: Sourcing your system through our authorized channels grants you full local protection. Any technical queries, battery changes, system expansion needs, or hardware faults are handled directly by our physical storefronts and on-call technicians right here in the Wellington region.

Gain absolute clarity and high-tier wireless protection for your home or business. Submit a request via our electronic security enquiry form or call our team directly on 0800 566 1111 ext 1 to secure your on-site consultation or security survey quote today!
